SLA-G Green energy relay
model | SLA-G |
Overall dimension (mm) | 31.8×27.4×19.8 |
Contact form: | 1a |
contact rating |
20A 250VAC;30A 250VAC;40A 277VAC
|
Coil power (W) | 0.9W |
0.8WCoil voltage (VDC) | 5~110VDC |
Contact resistance | ≤100mΩ |
ambient temperature | -40℃~+75℃ |
Installation form | Printed board, socket type |
